SENKO Single Mode LC Snap-In Fiber Connectors

SENKO Single Mode Fiber Connectors

LC Snap-In Connectors

Description

This LC (Lucent Connector) connector was developed to meet the need for smaller and easier-to-use fiber optic connectors. The LC connector reduces the space required on panels by 50% compared to SC connectors. Packaged with a strain relief boot for Ø900 µm, Ø2.0 mm, or Ø3.0mm tubing and a dust cap, this connector has a Ø1.25 mm, spring-loaded, ceramic ferrule and a typical insertion loss of 0.10dB. We also offer loose ceramic LC/PC ferrules as well as splice-ready LC/PC connectors (pigtails).

As an alternative to buying and assembling separate optical fiber, connectors, furcation tubing, termination tools, and consumables, we also offer pre-built patch cables from stock. Custom patch cables are available.

Features

* LC Connector

* Smaller Ferrule and Housing Size than SC Connectors

* Spring-Loaded, Ø1.25 mm, Ceramic Ferrule

* Strain Relief Boot for Ø900 µm, Ø2.0 mm, or Ø3.0mm Tubing and Connector Cap Included

Standard ferrule configuration

* Single Mode, Ø126 µm Bore, Ceramic Ferrule, Ø1.25 mm External Diameter Ferrules Embedded in Copper Tail.

* Customized Ceramic or Stainless-steel Ferrule is available, sold separately, please contact us for details.

Specifications & Order Information
